BUENO PFA Lined Pipes and Fittings

A range of PFA-lined pipes and fittings. The catalog includes pipes, elbows, tees, reducers, crosses and sight glasses. Metal-part materials and dimensions must be checked in the table for each product.

BUENO PFA Lined Pipes and FittingsBUENO PFA Lined Pipes and Fittings 2

Specifications

Pipe design standardASME B36.10
Fitting and flange standardASME B16.5 CLASS 150
Metal pipe thickness standardSchedule 40
Pipe metal part (carbon steel)ASTM A587 or ASTM A53 grade B
Pipe metal part (stainless steel)ASTM A312
Pipe flange material (carbon steel)ASTM A105
Pipe flange material (stainless steel)ASTM A182
Pipe flange configuration1 fixed flange and 1 loose flange
Lining materialPFA
Spiral tube modelMCT / CT
MCT wire mesh materialSS304
MCT wire mesh thickness1 mm
Instrument connection and armored spacer shellASTM A48 grade 25
Solid spacer materialPTFE / TFM1600
Blind flange materialASTM A105

Frequently Asked Questions

How are the metal specifications for pipes and flanges distinguished?
Pipe metal part (carbon steel): ASTM A587 or ASTM A53 grade B. Pipe metal part (stainless steel): ASTM A312. Pipe flange material (carbon steel): ASTM A105. Pipe flange material (stainless steel): ASTM A182.
What are the materials of the MCT tube and wire mesh?
The catalog labels the tube ‘PFA SPIRAL TUBE MCT & CT TYPE’. The MCT wire mesh material is SS304.
What pipe design and fitting/flange standards are listed?
Pipe design standard: ASME B36.10. Fitting and flange standard: ASME B16.5 CLASS 150. Metal pipe thickness standard: Schedule 40.
