EXA is a pilot operated 2-port solenoid valve that is NC (open when energized). It is dedicated to compressed air with a diaphragm drive, and its ports are ø6, ø8, ø10 and ø12 push-in fittings.
| Working Fluid | Compressed air |
| Valve Structure | Pilot operated diaphragm drive, NC |
| Working Pressure Differential | 0.01 to 0.7 MPa |
| Max. Working Pressure | 0.7 MPa |
| Proof Pressure | 1.05 MPa (water pressure) |
| Fluid Temperature | 0 to 55 °C (no freezing) |
| Ambient Temperature | -5 to 55 °C |
| Atmosphere | Place free of corrosive gas and explosive gas and not exposed to water |
| Internal Leakage | 2 cm³/min or less |
| External Leakage | 2 cm³/min or less |
| Port Size | Push-in fitting ø6, ø8, ø10, ø12 (EXA-C6 / C8 / C10 / C12) |
| Flow Characteristic C | 1.6 / 3.0 / 3.3 / 3.6 dm³/(s·bar) (ø6 / ø8 / ø10 / ø12) |
| Weight | 56 / 57 / 68 / 69 g (ø6 / ø8 / ø10 / ø12) |
| Mounting Orientation | Unrestricted |
| Rated Voltage | 100 VAC (50/60 Hz), 24 VDC, 12 VDC |
| Power Consumption | AC 1.2 VA, DC 0.6 W |
| Thermal Class | Class 130 (B) |
| Degree of Protection | Lead wire: IPX0, with DIN terminal box: IPX5 |
