| Nominal Bore | DN 100 - DN 2200 |
| Pressure Rating | PN 10, PN 16, PN 25, PN 40 |
| Operating Temperature Range | -15°C to +80°C |
| Flange Accommodation | EN 1092, AS 2129, AS4087, ANSI B16.5, AWWA C207 |
| Face-to-Face | EN 558-1 series 14, DIN 3202 F4, EN 558-1 series 13 |
| Testing | EN 12266-1, API 598, AS 4795.2 |
| Coating | DN 100 - DN 1800 Fusion Bonded Epoxy (FBE), DN 2000 - DN 2200 Two Pack Liquid Epoxy |
| Body Material | Ductile iron 5.3106 (optional: Stainless steel, Nickel aluminum bronze) |
