| Nominal Bore | DN 50 - DN 600 |
| Working Pressure | ≤DN150 40bar / >DN150 25bar |
| Operating Temperature Range | -60°C to +600°C |
| Flange Accommodation | EN 1092 PN 10/16/25/40 (up to DN150), PN 10/16/25 (DN200-DN600), ASME Class 150/300, AS 4087 PN16/21 |
| Face-to-Face | EN 558 Series 16, ISO 5752 Series 16 |
| Vacuum | up to 1 mbar absolute |
| Body Material | Carbon steel GS-C25N (1.0619, WCB) / Stainless steel G-X5CrNiMo19-11-2 (1.4408, CF8M) / Duplex steel GX2CrNiMoN26-7-4 (1.4469) |
