| Size | DN 250 / DN 300 |
| Nominal Bore | DN 250 / DN 300 |
| Body Material | Aluminum (GD-AlSi9Cu3) |
| Operating Temperature Range | -20°C to +130°C |
| Working Pressure | max. 1 bar |
| Seat Material | EPDM, NBR, FPM, SBR (green) |
| Disc Material | G-X6CrNiMo18-10 (1.4408), X2CrNiMo17-12-2 (1.4404) |
