| Body Material | 316 stainless steel |
| Cycle Life | More than 50,000 operations |
| Maximum Working Pressure | 2500 psig @70°F (172 bar @21°C) |
| Seat Material (standard) | 15% graphite-filled PTFE |
| Operating Temperature Range (FKM (Viton) seat ring) | -20°F~+450°F(-29°C~+232°C) |
| Cv Coefficient Range | 1.0~38.0 (varies by 7D/7E/7F sub-series) |
