| Body Material | 316 stainless steel, brass, Monel |
| Maximum Working Pressure | Brass 3000 psig(206.84 bar) @70°F(21°C); stainless steel/Monel 6000 psig(414 bar) @70°F(21°C) |
| Standard Cracking Pressure | 2 psig |
| Operating Temperature Range | NBR: -40°F~200°F(-40°C~93°C); FKM: -20°F~350°F(-29°C~177°C) |
| Orifice Size | 0.187"(4.75mm), 0.422"(10.7mm) |
| Cv Coefficient | 0.3, 2.4 |
| Seat Material | 6100 Series: NBR (brass body), FKM (Viton) (SS316 / Monel body) / 6200 Series: FKM (Viton); NBR for 3/8″ and 1/2″ female NPT |
