| Body Material | 316 stainless steel or brass |
| Operating Temperature Range (Buna-N O-ring packing) | -40°F~200°F (-40°C~93°C) |
| Operating Temperature Range (PTFE packing) | -60°F~250°F (-51°C~121°C) |
| Orifice Size | 0.062"(1.59mm), 0.125"(3.17mm) |
| Maximum Operating Pressure | Brass: 3000 psig (207 bar) up to 200°F (93°C); 316 stainless steel: 3000 psig (207 bar) @ 100°F (38°C), 1000 psig (68.9 bar) @ 250°F (121°C) |
| Seat Material | SS316 body: PCTFE |
