Model: GLCC01A1A
| Body Material | Zinc (electrostatic epoxy coating) |
| Sealing Class | NEMA 1,4,12,13; IP66 (GLC Series) |
| Conduit Entry | 20 mm |
| Operating Temperature | -40~85C[-40~185F] (GLC Series) |
| Thermal Current | 10 A |
| Rated Insulation Voltage | 300 V |
| Rated Impulse Voltage | 2.5 kV |
| Mechanical Life | Up to 10 million cycles |
| Pollution Degree | 3 |
| Maximum Actuation Frequency | 250 operations/minute |
| Shock | 50 g (IEC 60068-2-27); IEC 61373 Class I Car B Type |
| Vibration | 10 g (IEC 60068-2-6); IEC 61373 Class I Car B Type |
| Electrical Rating | AC-15 A300: 120 V / 6 A, 240 V / 3 A; DC-13 Q300: 125 V / 0.55 A, 250 V / 0.27 A |
| Make/Break Capacity | AC: 7200 / 720 VA; DC: 69 / 69 VA |
| Contact Configuration | 1NC/1NO (SPDT) |
| Contact Type | Snap action (Zb) |
| Contact Material | Silver |
| Actuation Type | Side rotary, plastic roller |
| Terminals | 13-14, 21-22 |
| Operating Torque | 0.12 N·m max. |
| Actuator Dimensions | Fixed nylon roller 19 × 6 mm |
| Operating Position | 26° |
| Release Position | 14.5° |
| Differential Travel | 11.5° |
| Total Travel | 70° min. |
