A ferrofluid rotary feedthrough that transfers rotation into vacuum, with magnetic fluid sealing the gap between the shaft and pole pieces like an O-ring. The non-contact seal has no friction, and flange mount, nose mount, hollow shaft and water-cooled spindle types are available.
| Type | Flange mount, nose mount, non-flange, nut bush, hollow shaft, semiconductor spindle (water-cooled available) |
| Vacuum Range | 1x10⁻⁸ mbar (solid shaft), 1x10⁻⁶ mbar (other types) |
| Leak Rate | <10⁻¹¹ to <10⁻¹² mbar·l/s (He) |
| Operating Temperature | 0 to 80 °C |
| Transfer Torque | 5 to over 5000 kg·cm |
| Applicable Gas | Inert gas |
| Material | Housing SS304, shaft SS420 |
