| Connection Size | G1/4, 1/4NPT or flange |
| Working Pressure Range | -1~30 bar (-14~435 psi) |
| Maximum Overpressure | 80 bar (1160 psi) |
| Mechanical Component Life | 10^7 switching cycles |
| Protection Rating | IP65 (DIN175301-803 connector), IP67 (M12x1 connector) |
| Material | Housing aluminum (brass), seals NBR/FPM |
| Operating Temperature Range | NBR: -10~+85°C (14~+185°F); FPM: 0~+80°C (0~+176°F); air supply must be dry enough to avoid ice formation below +2°C (+35°F) |
