| Size | 1/8" / 1/4" |
| Working Fluid | Compressed air, neutral gases |
| Maximum Pressure | 300 psig (20 bar) |
| Operating Temperature Range | 0°F~150°F (-20°C~65°C) |
| Gauge Port | 1/8" PTF (main port), 1/8" ISO-Rc (ISO G main port) |
| Material | Body zinc, bonnet acetal, valve seat polyphenylene, elastomers NBR |
| Seat Material | Polyphenylene |
| Body Material | Zinc |
| Seal Material | NBR |
