| Cylinder Bore Range | ⌀32~125mm |
| Torque Range | 1.2~510 Nm |
| Rotation Angle | 90°, 180°, 270°, 360° (adjustable) |
| Working Pressure | 1~10 bar (14.5~145 psi) |
| Operating Temperature Range | -5°C~+80°C (+23°F~+176°F, dry air required below +2°C(+35°F)) |
| Material | Profile barrel anodized aluminum, rack normalized (heat-treated) steel, pinion case-hardened high-strength steel, piston seals PUR, O-rings NBR |
