| Stroke / Angle | Linear type 5-130 mm (up to 200 mm on request) / Rotary type 25-120 deg |
| Air Supply Pressure | 1.4-7.0 bar (20-100 psi) |
| Input Signal | 4-20 mA @ 24 VDC (Profibus-PA/Fieldbus 9-32 VDC) |
| Operating Temperature | -30~+75°C (-22~+167°F), -40°C on request |
| Pneumatic Connections | PT(Rc) 1/4 or NPT 1/4 |
| Electrical Connection | 2 x PF(G) 1/2, NPT 1/2, M20 x 1.5 |
| Protection Rating | Flameproof IECEx / ATEX / KC Ex d IIC T6, IP66 |
| Body Material | Aluminum die-cast / powder-painted |
| Weight | 2.8 kg |
| Linearity / Hysteresis / Repeatability | Linearity < ±0.3% F.S, Hysteresis < 0.2% F.S, Sensitivity < 0.2% F.S, Repeatability < 0.2% F.S |
