| Torque Range | 75 to 200,000 Nm (55 to 147,500 lbf.ft) |
| Operating Temperature | -50 to +70 °C |
| Safety Rating | IEC 61508-2:2010 certified, suitable for SIL 2 / SIL 3 systems (Systematic Capability SC-3) |
| Protection Rating | Control module IP66/68, complete unit IP66/67 |
| Explosion Protection | Ex d IIB/IIC T4 (when specified) |
| Linear Thrust | up to 400 kN (90,000 lbf) |
| Position Control Resolution | <0.25% |
