| Maximum Inlet Pressure | 3500 or 500 psig (241 or 34.5 bar) |
| Outlet Pressure Range | 25, 50, 100, 250, 500 psig (1.7, 3.5, 6.9, 17.3, 34.5 bar) |
| Operating Temperature | PCTFE seat: -40 ~ 60 °C (-40 ~ 140 °F); Vespel seat: -40 ~ 177 °C (-40 ~ 350 °F) |
| Design Proof Pressure | 150% of maximum rated |
| Flow Capacity (Cv) | 0.06 Cv at 3500 psig / 241 bar; 0.2 Cv at 500 psig |
| Helium Leak (inboard) | 2x10^-8 atm cc/sec |
