| Relay Contact | 30 VDC @ 1A, 125 VAC @ 0.5A |
| Measuring Range | up to 10^-9 ~ 1000 Torr (depends on gauge range, N2 basis) |
| Dimensions | W 96 x H 48 x D 180 mm, weight 700~800 g (depends on options) |
| Input Power | 100~240 VAC @50/60 Hz, fuse 250 VAC @ 3A |
| Output Power | +15 VDC ±5% @500mA |
| Input/Output Signal | Input 2~10.000 VDC (default) / Output 2~10.000 VDC (default) |
| Display | 128*32 OLED LCD 5 digit |
| Ambient Operating Temperature | 15~50°C (59~122°F) |
| Options | R: RS232C PC interface, 4: RS485, A: Analog In/Out, L: Relay trip point limit (model RU100-A-B) |
