| Working Pressure | Vac to 6200 psig |
| Operating Temperature | -20 to 300 °F |
| Actuation Pressure | C40 75 to 120 psig, P40 75 to 120 psig (K20 n/a) |
| Wetted Surface Body Material | 316L VAR Stainless Steel |
| Diaphragm / Seat | Diaphragm: Elgiloy, Seat: Vespel |
| Actuation Type | C40 Pneumatic N.C. / P40 Pneumatic N.O. / K20 Manual 1/4 turn, LOTO |
| Flow Coefficient Cv | 0.16 |
| Helium Leak Rate | 1 x 10^-9 scc/s He |
| End Connection | 1/4 in OD tube stub .049 in wall; swivel female / swivel male / fixed male face seal |
| Proof / Burst Pressure | 150% / 300% of operating pressures |
