| Working Pressure | Vac to 4,500 psig |
| Flow Coefficient Cv | 0.5 |
| Proof / Burst Pressure | 150% / 300% of operating pressures |
| Operating Temperature | -20 to 300 °F |
| Wetted Surface Body Material | 316L VAR Stainless Steel |
| Diaphragm / Seat | Diaphragm: Elgiloy, Seat: Vespel SP-1 |
| Actuation Type | K30 Manual 1/2 turn, LOTO / P40 Pneumatic N.O. / C40 Pneumatic N.C. |
| Actuation Pressure | P40 75 to 120 psig, C40 75 to 120 psig (K30 n/a) |
| Helium Leak Rate | 1 x 10^-9 scc/s He |
| End Connection | 3/8 in tube stub .049 in wall; 1/2 in tube stub .065 in wall |
