| Input Signal | 0.2-1.0 bar (3-15 psi) |
| Supply Air Pressure | max. 7.0 bar (100 psi) |
| Standard Stroke | PPL (linear, lever feedback) 10-80 mm / PPR (rotary, cam feedback) 60-100 deg |
| Pneumatic Connection | PT(Rc) 1/4 or NPT 1/4 |
| Ambient Operating Temperature | -20~+70°C (high temp option up to +120°C; PPR +85°C with feedback options) |
| Pressure Gauge | Stainless steel |
| Air Consumption | 5 LPM (Sup. 1.4 bar) |
| Flow Capacity | 80 LPM (Sup. 1.4 bar) |
| Body Material | Aluminium die-cast |
| Weight | PPL 2.1 kg / PPR 2.5 kg |
