The 20CC and 20CF are miniature 2-way direct acting solenoid valves with a stainless steel body. They have 1/8" NPT ports, come in normally closed and normally open versions, and are used for air, inert gas, water and light oil.
| Actuation Type | Direct acting, 2-way normally closed (20CC) / normally open (20CF) |
| Body Material | Stainless steel |
| Port Size | 1/8" NPT |
| Orifice Size | 1/32" to 5/32" |
| Cv Value | 0.02 to 0.38 |
| Operating Pressure Differential | 0 to 950 psi (MOPD, AC) |
| Fluid Temperature | 240 °F or less |
| Seal Material | FKM |
| Power Consumption | 8 to 10 W |
