Sanitary 3pc Pneumatic Ball Valve (SUS316, Double Acting)

Model: PSVP-01

PSVP-01 is a sanitary ball valve combining a SUS316 body with a 3PC construction, a pneumatic double-acting actuator, and a PTFE seat. With 3A sanitary standard design principles, CLEAN AND OIL FREE treatment, and an ISO5211 direct mounting pad as standard specifications, it is used for high-speed automatic shutoff lines in pharmaceutical, biotechnology, chemical, food and beverage, and secondary battery processes.

Features

Sanitary 3pc Pneumatic Ball Valve (SUS316, Double Acting) PSVP-01

Frequently Asked Questions

How do I choose between double-acting and single-acting?
Double-acting offers fast response and large torque margin, suitable for high-frequency repeated control, but position retention is uncertain when pneumatic pressure is lost. Single-acting allows fail-safe return and is suitable for lines where safety shutoff is critical. Choose double-acting (PSVP-01) when high-speed automatic control is the priority, and single-acting (PSVP-02) when safety shutoff is the priority.
What advantages does the 3PC structure provide for sanitary lines?
In 3PC, the central body and both ferrule caps can be separated, allowing maintenance of seats, balls, and seals without disassembling the piping. This shortens maintenance cycles in sanitary lines with frequent CIP/SIP cycles and contributes to reducing line downtime.
What accessories can be attached to pneumatic valves?
Integrated packages combining various accessories tailored to site requirements can be supplied. Typical accessories include limit switch boxes, solenoid valves, and air filter regulators.
To what extent are 3A design principles applied?
PSVP-01 is manufactured reflecting the surface finish, dead-space minimization, and cleanability principles required by the 3A sanitary standard. If your project requires issuance of an official certificate, please notify us in advance and we will advise on availability.
